HDMI to HDMI + RCA Converter Splitter

Name: HDMI to HDMI + RCA Converter Splitter | 1080P & NTSC/PAL
Brand: Sun Cheong Computer Company Limited
SKU: 21SH000172
Price: 299.0 HKD
Availability: InStock

Short Product Description

This versatile HDMI to HDMI + RCA (AV) converter acts as a 1-in-2-out splitter, allowing you to connect modern HDMI devices to both a new HD TV and an older analog TV simultaneously. Supporting up to 4K@30Hz input and 1080P@60Hz output, it features a built-in NTSC/PAL switch and a durable metal shell for excellent heat dissipation. Perfect for retro gaming, karaoke setups, and reviving vintage displays. Available in-stock at Sun Cheong Computer Co. Ltd. (新昌電腦有限公司) in Sham Shui Po.

Key Features

1-in-2-Out Splitter: Distributes a single HDMI input to both an HDMI output and an RCA (CVBS + L/R Audio) output simultaneously.
High-Resolution Support: Accepts HDMI inputs up to 4K@30Hz and outputs crisp 1080P@60Hz via the HDMI pass-through.
NTSC / PAL Switch: Easily toggle between regional analog TV standards to fix black-and-white or rolling picture issues on older TVs.
Plug and Play: No drivers or software installation required; simply connect your cables and power it up.
Durable Metal Shell: The robust metal casing provides excellent heat dissipation, ensuring stable 24/7 operation without overheating.
HDCP Compliant: Supports HDCP protocols and HDMI 1.3, ensuring compatibility with modern streaming sticks and DVD players.

Full Product Description

Bridge the Gap Between Old and New Displays

This HD Video Converter is the ultimate solution for connecting modern HDMI source devices—such as an Apple TV, PS4, Xbox, or Roku—to older televisions that only have RCA (Red/White/Yellow) inputs. Unlike standard adapters, this device functions as a splitter: it provides both an RCA composite output and an HDMI pass-through output. This means you can play a game or watch a movie on your modern 1080p flat screen while simultaneously sending the exact same video and audio to a vintage CRT TV or an older projector in another room.

Built-in Scaler and NTSC/PAL Switch

Equipped with an advanced internal IC chip, this converter automatically scales digital HDMI signals down to standard analog composite signals (480i/576i) without lag or signal loss. It features a convenient physical switch to toggle between NTSC and PAL standard TV formats. If your older TV displays a black-and-white or rolling image, simply flip the switch to instantly correct the regional format compatibility.

Technician Tip

When using this converter, you must connect the included USB power cable to a 5V/1A power source (like a phone charger or a powered USB port on your TV) for the internal IC chip to function. Please note a technical limitation: while the HDMI pass-through supports up to 4K@30Hz when used alone, if you connect both the HDMI and RCA outputs simultaneously, the maximum resolution for the HDMI output will be capped at 1080P. If you need extra RCA or HDMI cables to complete your setup, visit our physical store at Sun Cheong Computer Co. Ltd. in Sham Shui Po.

Technical Specifications

Input Port: 1x HDMI (Female)
Output Ports: 1x HDMI (Female), 3x RCA (Yellow/White/Red - CVBS + L/R Audio)
Supported Input Resolution: Up to 4K@30Hz, 1080P@60Hz
HDMI Output Resolution: Up to 4K@30Hz (Standalone) / Max 1080P (When used simultaneously with RCA)
RCA Output Resolution: 480i (NTSC) / 576i (PAL)
TV Format Support: NTSC / PAL (Selectable via switch)
Power Requirement: DC 5V/1A (USB Power Cable Included)
Housing Material: Metal Shell

Delivery Options

Local delivery within Hong Kong and in-store pickup.
Free shipping for orders of HK$400 or above; HK$35 shipping fee for orders below HK$400.
Shipped by SF Express, usually dispatched the same day for orders confirmed before 6:00 PM (Mon–Sat).
Estimated delivery time: 1–3 business days after dispatch (Hong Kong).
In-store pickup details (location and time) will be confirmed by email or phone message.
Delivery times are estimates and may be affected by weather or unforeseen circumstances.

FAQ Section

Can I connect my PS5 to an old tube TV with this?

Yes, you can connect the HDMI output from your PS5 (or any modern console) into the input of this converter, and then use standard RCA cables to connect the converter to your old tube (CRT) TV.

Why is the picture on my old TV showing in black and white?

This happens when the video format doesn't match your TV's regional standard. Simply locate the NTSC/PAL switch on the side of the converter and flip it to the other setting to restore full color.

Do I need to plug it into a power outlet?

Yes, this converter contains an active IC chip that requires power to downscale the digital signal to analog. You must connect the included USB power cable to a 5V/1A USB wall charger or a powered USB port on your TV/console.

Will the HDMI output still be 4K if I use the RCA output at the same time?

No. While the HDMI pass-through supports 4K@30Hz when used by itself, if you have both the HDMI and RCA cables connected to displays simultaneously, the maximum resolution of the HDMI output will automatically scale down to 1080P.

Is this HDMI to RCA converter available at your Sham Shui Po store?

Yes, we stock this HDMI to HDMI + RCA converter at our Sham Shui Po physical store. You can order it online for delivery or drop by during business hours for immediate pickup.

Target Users / Applications

Retro Gamers: Connecting modern HDMI consoles to vintage CRT televisions for a nostalgic, zero-lag analog feel.
Karaoke Enthusiasts: Splitting the video signal from a smart TV box to a modern TV for lyrics, while sending the RCA audio to an older, powerful analog amplifier.
Bar & Restaurant Owners: Distributing a single sports broadcast from a modern set-top box to both a new flat-screen and an older projector simultaneously.
Digital Signage Installers: Bridging the gap between new HDMI media players and legacy analog display infrastructure without replacing the screens.
