EIGHT TV Amplifier (Home Use)
EIGHT TV Amplifier (Home Use)
  • Load image into Gallery viewer, EIGHT TV Amplifier (Home Use)
  • Load image into Gallery viewer, EIGHT TV Amplifier (Home Use)

EIGHT TV Amplifier (Home Use)

Regular price
$148.00
Sale price
$148.00
Regular price
Sold out
Unit price
per

Eight TV Amplifier - Boosts TV Signals Adjustable Gain Controls



1 year warranty



Features

  • Output: 2
  • VHF:40MHz~230MHz
  • UHF:470MHz~862MHz
  • Boosts TV / Radio analog and digital signals
  • Separate adjustable gain controls for UHF and VHF
  • DC Power input
  • Accessories included for wall mount
  • Enhances performance of all passive outdoor antennas while challenging reception issues



Specification

General

Band Coverage: VHF: 40~230MHz

UHF: 470~862MHz

Gain : VHF: 19.5dB

UHF: 21dB

Regulation: VHF: 18dB

UHF: 16dB

Noise Figure: VHF: 5.5dB

UHF: 4.3dB

Number of Output: 2

Max Output Level: 110dBμv

Input / Output Impedance: 75ohm

Power Supply Input Voltage:100~240/Vac

DC IN: DC 5V/2A

Operating Temperature Range: 0~50˚C

Connectors: IEC
