12.6V 5A Smart Li-ion Battery Charger for 3-Series 18650 Packs

Reliable & Intelligent Charging for Your 12V Lithium Battery Packs!

Ensure optimal performance and longevity for your 3-series 12V Li-ion battery packs with this intelligent 12.6V 5A charger. Specifically designed for 18650 and similar lithium-ion batteries, this charger provides a safe and efficient charging solution for various applications, from DIY projects to electric vehicles and more.

Smart Charging with Advanced Protection:

Equipped with comprehensive safety features, this charger protects your batteries and itself from common electrical issues. The built-in indicator light clearly shows charging status: red for charging and green for fully charged.

Specifications:

• Input: 100-240VAC, 50/60Hz (Global Compatibility)
• Output: 12.6V 5A
• Charge Indicator: Red light for charging, Green light for full charge
• Security Protection: Over Voltage Protection (OVP), Over Current Protection (OCP), Overload Protection, Short-circuit Protection
• Color: Black
• DC Output Connector: 5.5*2.1mm

Important Use and Maintenance Tips:

To maximize the life of your charger and battery, please follow these guidelines:

1. Correct Connection Order: Always connect the charger to the battery first, then plug into the AC power outlet. After charging is complete, unplug from AC power before disconnecting the battery. This prevents damage to the charger, especially when charging at high currents.
2. Optimal Full Charge: Once the LED light turns green (indicating a full charge), continue charging for an additional 2-3 hours to ensure a balanced and complete charge.
3. Avoid Deep Discharge: Do not allow your battery to completely drain before charging. This can damage the battery and prevent proper protection.
4. Periodic Deep Discharge (for long-term shallow discharge batteries): For batteries that are frequently shallow-discharged, perform a deep discharge (until the controller's undervoltage protection activates) approximately every 3 months. This "re-lighting" helps activate inactive material within the battery and prolong its life.
5. Dry Environment: Always use the charger in a dry environment.
6. Unplug When Not In Use: Disconnect the charger from the power supply when not actively charging.
7. Battery Compatibility: This charger is specifically designed for Lithium-Ion (Li-ion) batteries (e.g., 18650). DO NOT use it with LiFePO4 batteries, as this can cause severe overheating and damage to the charger.

Package Included:

• 1 x 12.6V 5A Lithium Battery Charger
• 1 x Power Cable
