1.6 inch SPI LCD Monitor 130*130 for Arduino

1.6 Inch OLED 1.6 TFT IPS OLED Transflective Display Module LCD Display DIY SPI Serial Port 130*130 Communicate for Arduino

Specification:

Screen Type: TFT

Screen Size: 1.6inch

Introduction:

1.6-inch color screen, support 65K color display, display rich colors

Semi-transparent LCD, superior performance, clearly visible under strong light

With SPI serial bus, only a few IO ports can be used to light up the display

Onboard 3.3V/5V power conversion chip, compatible with 3.3V and 5V voltage levels

Operating temperature range is industrial grade (-20 ° C ~ 70 ° C)

Provide rich multi-platform routines

Provide underlying driver technical support

Support backlight control

Electrical Parameters:

Display Color: 65K

Driver IC: SSD1283A

Resolution: 130 x 130(Pixel)

Viewing Angle: ≥60Degrees.

Operating Voltage: 3.3V/5V

Power Consumption: app.100mA(Full Brightness), app.10mA(All)
